Descripción
| IMPEDÂNCIA DO AMPLIFICADOR
IMPEDANCE OF THE AMPLIFIER |
0.5Ω |
LOAD / CHARGE 1Ω 2Ω |
4Ω |
||
| Power / Power RMS @ 12.6V 0.5Ω | 3670W | 2540W | 1760W | 1190W | |
| Potência / Power RMS @ 12,6V | 1Ω | – | 3670W | 2540W | 1760W |
| Potência / Power RMS @ 12,6V | 2Ω | – | – | 3670W | 2540W |
| Potência / Power RMS @ 12,6V | 4Ω | – | – | – | 3670W |
| Potência / Power RMS @ 14,4V 0,5Ω | 4740W | 3310W | 2320W | 1625W | |
| Potência / Power RMS @ 14,4V | 1Ω | – | 4740W | 3310W | 2320W |
| Potência / Power RMS @ 14,4V | 2Ω | – | – | 4740W | 3310W |
| Potência / Power RMS @ 14,4V | 4Ω | – | – | – | 4740W |
Tensão de Alimentação / Power Supply 7Vdc ~ 16Vdc Consumption in Repouso / Consumption at Rest 1,5A
Consumo Musical / Music Consumption 170A
Cons. Max. em Sinal Senoidal 40Hz / Max. Consump. in Sinusoidal Signal 40Hz 388A Efficiency / Efficiency 75%
Input Impedance / Input Impedance 22K Ohms
Input Sensitivity / Input Sensitivity 0.25V ~ 6V Total Harmonic Distortion / THD 0.1%
SNR> 90dB
Fator Amount / Damping Factor 40Hz (12 , 6V 2?)> 1000 Frequency Response / Frequency Response 5Hz ~ 45KHz (-3dB) Low Pass Crossover 80Hz ~ 20KHz
High Pass Crossover 5Hz ~ 200Hz
Ganho do Reforço / Boost Gain 0dB ~ 18dB
Frequency of Reforço Variável / Frequency of Variable Reinforcement. 28Hz ~ 400Hz Limiter Threshold Variável / Variable Threshold Limiter
Dimensions / Dimensions (AxLxC) mm 70x280x260 Weight per pack / Weight if Packing 3.95Kg
