Descripción
| IMPEDÂNCIA DO AMPLIFICADOR
IMPEDANCE OF THE AMPLIFIER |
0.5Ω |
LOAD / CHARGE 1Ω 2Ω |
4Ω |
||
| Power / Power RMS @ 12.6V 0.5Ω | 5600W | 3700W | 2500W | 1700W | |
| Potência / Power RMS @ 12,6V | 1Ω | – | 5600W | 3700W | 2500W |
| Potência / Power RMS @ 12,6V | 2Ω | – | – | 5600W | 3700W |
| Potência / Power RMS @ 12,6V | 4Ω | – | – | – | 5600W |
| Potência / Power RMS @ 14,4V 0,5Ω | 6400W | 4300W | 2900W | 1900W | |
| Potência / Power RMS @ 14,4V | 1Ω | – | 6400W | 4300W | 2900W |
| Potência / Power RMS @ 14,4V | 2Ω | – | – | 6400W | 4300W |
| Potência / Power RMS @ 14,4V | 4Ω | – | – | – | 6400W |
Tensão de Alimentação / Power Supply 7Vdc ~ 16Vdc Consumption in Repouso / Consumption at Rest 2.5A
Music Consumption / Music Consumption 280A
Cons. Max. em Sinal Senoidal 40Hz / Max. Consump. in Sinusoidal Signal 40Hz 592A Efficiency / Efficiency 75%
Input Impedance / Input Impedance 22K Ohms
Input Sensitivity / Input Sensitivity 0.25V ~ 6V Total Harmonic Distortion / THD 0.1%
SNR> 90dB
Fator Amount / Damping Factor 40Hz (12, 6V 2?)> 1000 Frequency Response / Frequency Response 5Hz ~ 20KHz (-1dB) Low Pass Crossover 80Hz ~ 20KHz
High Pass Crossover 5Hz ~ 200Hz
Ganho do Reforço / Boost Gain 0dB ~ 18dB
Frequency of Variable Reform / Frequency of Variable Reinforcement.28Hz ~ 400Hz Limiter Threshold Variable / Variable Threshold Limiter
Dimensions / Dimensions
